该系统是我公司采用市场前沿技术结合广大用户需求开发研制的新一代龙门式埋弧焊自动控制设备,控制器采用了成熟可靠的控制技术和控制理论,深入用户需求,实现了市场前沿技术与适用性的结合、统一。 This system is a new generation gantry submerged arc welding automatic control equipment developed by our company using cutting-edge market technology combined with the needs of a wide range of users. The controller adopts mature and reliable control technology and theory, deeply understands user needs, and achieves the combination and unity of cutting-edge market technology and applicability.
系统特点
1、点动送丝时,焊丝接触工件自动停止下送,防止顶弯焊丝和影响引弧。焊丝粘接工件时可强迫送丝。
2、同一机头的直流焊机和交流焊机可同时启停、交流延时启停也可分别启停。
3、在触摸屏上显示参数数据及触控操作,更方便,更直观。
4、参数可断电保存。
5、参数可通过 USB 导出或导入,多焊机可实现参数共享。
6、完善的权限管理,可设置不同级别、不同操作员的权限。
7、报表数据在焊接完成后保存,并可通过 USB 导出。
8、可扩展有线和无线网络控制,并可扩展集控系统进行集中管理。
System Characteristics
1. When tapping the wire feed, the wire will automatically stop feeding when it contacts the workpiece, preventing the wire from bending and affecting arc initiation. Wire feeding can be forced when bonding workpieces with welding wire.
2. The DC welding machine and AC welding machine with the same head can be started and stopped simultaneously, and the AC delayed start and stop can also be started and stopped separately.
3. Displaying parameter data and touch operations on the touch screen is more convenient and intuitive.
4. The parameters can be saved with power off.
5. Parameters can be exported or imported through USB, and multiple welding machines can achieve parameter sharing.
6. Complete permission management, allowing for the setting of permissions for different levels and operators.
7. The report data is saved after welding is completed and can be exported via USB.
8. Scalable wired and wireless network control, and expandable centralized control system for centralized management.
