焊机的额定焊接电流对应相应的额定负载持续率,当负载持续率提高时,焊机的最大输出电流相应降低。如负载持续率由60%提高到100%时,最大输出电流为额定焊接电流的0.7746倍。当环境条件超过正常使用环境时,焊机也应降额使用。如果发热试验已在室温下完成,则应通过模拟的方法来确认环境温度40°C条件下的负载持续率。The rated welding current of the welding machine corresponds to the corresponding rated load duration rate. When the load duration rate increases, the maximum output current of the welding machine decreases accordingly. When the load duration rate increases from 60% to 100%, the maximum output current is 0.7746 times the rated welding current. When the environmental conditions exceed the normal usage environment, the welding machine should also be downgraded for use. If the heating test has been completed at room temperature, the load duration at an ambient temperature of 40 ° C should be confirmed through simulation.
产品特点
1、采用IGBT逆变技术,保证焊接规范在电网电压和电弧长度变化时的高度稳定。
2、功率和效率因数高,因而有显著的节电效果和较高的电网利用率。
3、电流调节范围宽。
4、可预置焊接电流或焊接电压。
5、体积小、重量轻。
Product Features
1. Adopting IGBT inverter technology to ensure high stability of welding specifications under changes in grid voltage and arc length.
2. High power and efficiency factors result in significant energy-saving effects and high grid utilization.
3. Wide range of current regulation.
4. Can preset welding current or welding voltage.
5. Small size and light weight.
